X-film self-cleaning ultraviolet resistance protective film
Release date: 20012/06/22

Product Introduction
X-film is a kind of self-cleaning ultraviolet resistance protective film with high transparency and high weather resistance, and is made under co-extrusion of PVDF and special PMMA, with excellent surface performances such as chemical resistance,  fouling resistance, graffiti resistance, easy cleanness, and etc.

Product Structure上海翻译公司完成自洁保护膜英文翻译
Surface film: It has high-quality PVDF (polyvinylidene fluoride) in the surface layer with thickness of 5 �m, commonly known as "teflon"; it has excellent "self-cleaning" performance;
Bottom layer: It has special ultraviolet resistance PMMA with thickness of 45�m; it has excellent weather resistance, ultraviolet resistance, printability and  thermal bonding.
Back adhesive: Transparent permanent crylic acid back adhesive
Bottom paper: White kraft paper in weight of 130 grams


Processing
Thin X-film can be  thermoformed and die cut. In addition, the thin film shows good performances in various printing process. It can be joint processed easily:


Performance Comparison Table

	Unit	X-film Self-cleaning Ultraviolet Resistance Protective Film	Test Method
Mechanical Properties
Tensile Modulus	MPa	1200	ISO527
Yield Stress	MPa	45	ISO527
Fracture Strain	%	>50	ISO527
Weather Resistance
Hernia Lamp Test 1200/5000 h	/	No change	/
Optical Properties
Light Transmittance	%	93	DIN 5036
Ultraviolet Transmissivity (280-380nm)	%	<2	DIN 67507
Haze	%	2	ASTM 1003
Yellow index	%	<1	ASTM D1925
Chemical Resistance (24 h/RT) "Drop Test", PVDF Coating Side
alcohol Methyl Ethyl Ketone Gasoline  N-Hexane  Benzene  Methylbenzene  Tetrahydrofuran Ethyl Acetate	Visual Inspection	No Change Slight Change  No Change No Change No Change No Change Slight Change Slight Change	/
Others
Density	G/ccm	1,2	ASTM D1505
Critical Surface Tension	mN/m	25



Characteristics
Ÿ  It can filter 65% of the ultraviolet ray, with extremely strong performance of UV resistance, which can enhance the durability of pictures (covered by X- film protective film, the pictures printed with solvent ink can last for 4-5 years without fading)
Ÿ  The transparency and outdoor weather resistance is significantly higher than PVC materials.
Ÿ  The strong corrosion resistance performance of PVDF can prevent the protected media such as pictures from yellowing and aging in a longer period of time
Ÿ   PVDF layer has good self-cleaning properties. After being covered by X-film protective film, pictures, dust on the signboards, stains, rain stains will be easier to clean;


Application
X-film self-cleaning ultraviolet resistance film is suitable to be used for protective layer on the surface of sheets such as PVC, PC, PMMA, ABS ans etc or base materials for thin films, and even surface coating film of fabric, wood, and metal .
Ÿ  Outdoor building materials
Ÿ  Exterior automobile parts
Ÿ  Interior automobile parts
Ÿ  Indoor building materials


Product characteristics

Physical characteristics

Characteristics         Test Method¹                                                     Result
Thickness of the surface film                                                                             ISO 534   50 mm
surface film+ Thickness of the back adhesive  ISO 534                                                                 80 mm
Glossiness                  ISO 2813，85°                                                     93 ％

Dimensional stability  DIN 38464                                                             £ 0.1 mm
Initial viscosity             ASTM 1000，stainless steel                             525 N/m
Final viscosity              ASTM 1000，stainless steel                             700 N/m

Inventory period        Stored in the environment with temperature of 23°C and relative humidity of 50-55%     2 years
Durability                     Mounted vertically                                             10 years

Service characteristics

Minimum temperature of the covering film                                             over +10°C
Range of operation temperatures:                                                           -40°C～+80°C


It is not recommended to be soaked in gasoline or similar solutions for a long time.

Cautions
Information about the physical and chemical properties of related materials are based on  test results we consider to be reliable. The listed of typical numerical values here are used as reference for material selection, and is not the guarantee.
The manufacturer is likely make modifications to related technical data without prior notice.

Quality assurance
X-film self-cleaning ultraviolet resistance film is produced under strict quality control system. Any sold material confirmed to be quality defects of the product itself will be returned and compensated unconditionally. The values of our returning and compensating  will not exceed the corresponding material prices. Any sales personnel or agent has no right to provide assurance, guarantee or contract with similar natures beyond the above statement.

1)   Test method上海翻译公司完成自洁保护膜英文翻译
Please visit our website for more information about the test method.

2)   Durability
The test benchmark is the outdoor environment in central Europe. The actual service life  depends on the preparation of substrate, service environment as well as the maintenance of the logo. For example, when the logo is placed toward the south, in the long-term high-temperature southern European regions, regions with industrial pollutions or in high altitudes, the outdoor service performance of the material will be reduced.
